Single-pixel imaging

Overview of the principle of single-pixel imaging.

Simulation of the measurements

Single-pixel imaging aims to recover an unknown image \(x\in\mathbb{R}^N\) from a few noisy observations

\[m \approx Hx,\]

where \(H\colon \mathbb{R}^{M\times N}\) is a linear measurement operator, \(M\) is the number of measurements and \(N\) is the number of pixels in the image.

In practice, measurements are obtained by uploading a set of light patterns onto a spatial light modulator (e.g., a digital micromirror device (DMD), see principle). Therefore, only positive patterns can be implemented. We model the actual acquisition process as

(1)\[y = \mathcal{N}(Ax)\]

where \(\mathcal{N} \colon \mathbb{R}^J \to \mathbb{R}^J\) represents a noise operator (e.g., Poisson or Poisson-Gaussian), \(A \in \mathbb{R}_+^{J\times N}\) is the actual acquisition operator that models the (positive) DMD patterns, and \(J\) is the number of DMD patterns.

Handling non negativity with pre-processing

We may preprocess the measurements before reconstruction to transform the actual measurements into the target measurements

(2)\[m = By \approx Hx\]

where \(B\colon\mathbb{R}^{J}\to \mathbb{R}^{M}\) is the preprocessing operator chosen such that \(BA=H\). Note that the noise of the preprocessed measurements \(m=By\) is not the same as that of the actual measurements \(y\).

Data-driven image reconstruction

Data-driven methods based on deep learning aim to find an estimate \(x^*\in \mathbb{R}^N\) of the unknown image \(x\) from the preprocessed measurements \(By\), using a reconstruction operator \(\mathcal{R}_{\theta^*} \colon \mathbb{R}^M \to \mathbb{R}^N\)

\[\mathcal{R}_{\theta^*}(m) = x^* \approx x,\]

where \(\theta^*\) represents the parameters learned during a training procedure.

Learning phase

In the case of supervised learning, it is assumed that a training dataset \(\{x^{(i)},y^{(i)}\}_{1 \le i \le I}\) of \(I\) pairs of ground truth images in \(\mathbb{R}^N\) and measurements in \(\mathbb{R}^M\) is available}. \(\theta^*\) is then obtained by solving

(3)\[\min_{\theta}\,{\sum_{i =1}^I \mathcal{L}\left(x^{(i)},\mathcal{R}_\theta(By^{(i)})\right)},\]

where \(\mathcal{L}\) is the training loss (e.g., squared error). In the case where only ground truth images \(\{x^{(i)}\}_{1 \le i \le I}\) are available, the associated measurements are simulated as \(y^{(i)} = \mathcal{N}(Ax^{(i)})\), \(1 \le i \le I\).

Reconstruction operator

A simple yet efficient method consists in correcting a traditional (e.g. linear) reconstruction by a data-driven nonlinear step

(4)\[\mathcal{R}_\theta = \mathcal{G}_\theta \circ \mathcal{R},\]

where \(\mathcal{R}\colon\mathbb{R}^{M}\to\mathbb{R}^N\) is a traditional hand-crafted (e.g., regularized) reconstruction operator and \(\mathcal{G}_\theta\colon\mathbb{R}^{N}\to\mathbb{R}^N\) is a nonlinear neural network that acts in the image domain.

Algorithm unfolding consists in defining \(\mathcal{R}_\theta\) from an iterative scheme

(5)\[\mathcal{R}_\theta = \mathcal{R}_{\theta_K} \circ ... \circ \mathcal{R}_{\theta_1},\]

where \(\mathcal{R}_{\theta_k}\) can be interpreted as the computation of the \(k\)-th iteration of the iterative scheme and \(\theta = \bigcup_{k} \theta_k\).
